1.Telecommunications
2.CATV, LAN, MAN, WAN, Test &Measurement
3.Military industry
4.Medical
1.Low insertion loss and back reflection loss
2.Ferrule end surface pre-domed
3.Excellent mechanical endurance
4.Good in repeatability
5.Good in exchange
6.Green Production, CE, RoHS Standard
|
Mode
|
Single mode
|
|
Multimode
|
||
|
Polish
|
UPC
|
APC
|
PC
|
||
|
Insertion Loss
|
≤0.30dB
|
≤0.20dB
|
≤0.20dB
|
||
|
Return Loss
|
≥50dB
|
≥60dB
|
≥30dB
|
||
|
Test Wavelength
|
1310/1550nm
|
|
850/1310nm
|
||
|
Durability(500 Matings)
|
≤0.2dB
|
|
|
||
|
Operating Temperature
|
-40℃~+60℃
|
|
|
||
|
Storage Temperature
|
-45℃~+85℃
|
|
|
||
|
Fire Resistant
|
IEC 60794-2-30
|
|
|
||
|
Standards-Compliant
|
ROHS,IEC and GR-326
|
|
|
||
|
Fiber type
|
Single mode:
|
(1)9/125-G652D
|
(2)9/125-G655
|
(3)9/125-G657A,G657A2
|
(4)9/125-G657B3
|
|
|||||
|
|
Multimode:
|
(5)50/125-OM2
|
(6)62.5/125-OM1
|
(7)50/125-OM3
|
(8)50/125-OM4
|
(9)50/125-OM5
|
|||||
|
Fiber Brand
|
YOFC, Corning, Sumitomo, Fujikura
|
|
|
|
|
|
|||||
|
Connector
|
SC/PC, SC/APC, LC/PC, LC/APC, FC/PC, FC/APC, ST/PC, E2000/PC, E2000/APC, MU/PC, MTRJ/Female, MTRJ/Male, MPO/MTP, DIN/PC, SMA/PC, D4/PC
|
|
|
|
|
|
|||||
|
Cord type
|
Simplex ,Duplex
|
|
|
|
|
|
|||||
|
Cable diameter
|
0.9mm ,1.2mm, 1.6mm, 1.8mm, 2.0mm, 2.8mm, 3.0mmm, 4.1mm
|
|
|
|
|
|
|||||
|
Cable jacket
|
PVC, OFNR, LSZH, OFNP
|
|
|
|
|
|
|||||
|
length(M)
|
0.5m,1m,2m,5m,10m,25m,50m,100m…Customized
|
|
|
|
|
|
|||||
