Flangeless SC Simplex Single Mode Adapter For CATV Telecommunication

100 pieces
MOQ
$0.10/pieces 100-999 pieces
Price
Flangeless SC Simplex Single Mode Adapter For CATV Telecommunication
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Enterprise Wireless Access Point
Product Name: Fiber Optic Adapter
No Of Fiber: 1
Connector Type: SC APC
Material: PC
Durability Time: >1000
Insertion Loss: 0.2db
Warranty: 1 Year
Working Condition: -40°C To +75°C
Working Wavelength: 1200~1600nm
Package: 50 Pc Per Box
High Light:

Flangeless SC Simplex Single Mode Adapter

,

CATV SC Simplex Single Mode Adapter

,

Telecommunication sc adapter single mode
Basic Infomation
Place of Origin: China
Brand Name: ODM/OEM
Certification: RoHS, CE
Model Number: fiber optic adapter
Payment & Shipping Terms
Packaging Details: by carton box
Payment Terms: T/T, Western Union
Product Description

SC APC single mode simplex adapters fiber optic connector flangeless

Product Description

Fiber optic adapter, sometimes also called coupler, is a small device designed to terminate or link the fiber optic cables or
fiber optic connectors between two fiber optic lines.

By linking two connectors precisely, fiber optic adapters allow the light sources to be transmitted at most and lower the loss as much as possible. At the same time, fiber optic adapters have the merits of low insertion loss, good interchangeability and reproducibility.
Flangeless SC Simplex Single Mode Adapter For CATV Telecommunication 0
Flangeless SC Simplex Single Mode Adapter For CATV Telecommunication 1
Flangeless SC Simplex Single Mode Adapter For CATV Telecommunication 2
Feature
* Low insertion loss
* High return loss
* Easy installation
* Various specifications
* Good interchangeability and duplication
* RoHs Compliance
Application
* Fiber optic transmission system
* Fiber optic sensing
* Fiber optic distribution frame
* Testing/Measurement Instruments
* LAN
* CATV
* Telecommunication networks
Specification
Sleeve Material:
Ceramic or beryllium bronze
Housing Material:
Synthetic resin or alloy, with high precisemechanical dimensions, good compatibility
Working Wavelength:
1200~1600nm
Working Condition:
-40°C to +75°C
Durability:
less than 500 times repeated insert and pull out , insertion loss change≤0.20dB
Repeatability:
No more than 0.2dB ;
Standard:
NTT/Telcordia/IEC/TIA/EIA.
Mode:
SM/APC Green SM/PC Blue MM/PC Beige MM/PC Light Green
