IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector

2 pieces
MOQ
$4.50 - $15.00/pieces
Price
IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Fiber Optic Patch Cord
Use: FTTH, FTTX
Network: 4g, 3G
Fiber Type: Singlemode
IP Protection Class: IP68
Connector A Type: SC/APC
Compatible Connector Type: Optitap Connector
Fiber Brand: Corning, YOFC, OFS
Insertion Loss: 0.2dB
Return Loss: >65dB
Length: Customized
No. Of Fiber: 1.
High Light:

Waterproof Ftth Drop Cable

,

IP68 Ftth Drop Cable

Basic Infomation
Place of Origin: China
Brand Name: ODM/OEM
Certification: RoHS, CE
Model Number: Waterproof patch cord
Payment & Shipping Terms
Packaging Details: 1pc/PE bag<br>according to customer's request.
Payment Terms: T/T, Western Union
Supply Ability: 20000 Piece/Pieces per Day
Product Description
Product Description
IP68 Waterproof Ftth Drop Cable Outdoor Fiber Optic Cable Assemblies Compatible optitap Connector

APPLICATION

Fiber optic communications in harsh outdoor environments
Outdoor communication equipment connection
waterproof fiber equipment SC port
Remote wireless base station
FTTx wiring project
IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector 0

Features

1. Compatible with Corning-OptiTap and H-Connector; 2. Factory terminated for high performance; 3. Available with one or both ends connectorized; 4. Hybrid (one end with an OptiTap Connector, one end with standard SC connector) available with or without pulling grip; 5. Available in dielectric or toneable; 6. Designed for aerial, direct-buried or duct installation; 7. IP-68 water and dust protection ; 8. -40℃~85℃ operating temperature;
Type
SM-UPC

SM-APC

MM-UPC


Typical
MAX
Typical
MAX
Typical
MAX
Insertion loss
≤0.1
≤0.3dB
≤0.15
≤0.3dB
≤0.05
≤0.3dB
Return loss
≥50dB

≥60dB

≥30dB

Durability
500 mating cycles





Working temperature
-40 to + 85℃






IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector 1
IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector 2
IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector 3
Company Profile
We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. With years of experiences in the fiber optic industry, our factory is fully equipped over 5000 square meters and more than 30 non dust production lines .About 250 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 15 production lines for standard jumper and 8 PLC Splitter production lines. The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on. All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, our fiber optic is looking forward to cooperate with you.
IP68 Waterproof Ftth Drop Cable Compatible with optitap Connector 4
FAQ
Q1. Do you provide OEM ODM service ? Yes, we can print your logo or label on the products or on the box.
Q2. How can you guarentee the quality ? Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q3. What is your delivery time ? Generally, sample: 3~5 working days. formal order: 7-10 working days.
Q4. What's the method of shipment? We accept all shipment , such as Delievery,ocean transport, land transport , airport transport.
Q5. What's the Payment? We accept all payments , such as LC,TT,DP,DA,Paypal,Western Union,Money Gram.
Q6. Do you provide sample service? A: Yes, we provide free or low price samples for you to test and check quality. Mixed samples are acceptable.
