Waterproof Rate
|
|
|
IP68.(1M ,1hour)
|
||
|
Applicable optical cable
|
|
|
2.0x3.0mm,3.0mm ,5.0mm
|
||
|
Insertion loss
|
|
|
≤0.50dB
|
||
|
Return loss
|
|
|
≥55dB
|
||
|
End face performance
|
|
|
Conform to YD T 2341.1-2011
|
||
|
Mechanical durability
|
|
|
1000 times
|
||
|
Cable tension
|
2.0x3.0mm (Ttap Fast Connector)
|
|
≥30N; 2Minute
|
||
|
|
2.0mm,3.0mm (Ttap Connector)
|
|
≥30N; 2Minute
|
||
|
|
5.0mm (Ttap Connector)
|
|
≥70N; 2Minute
|
||
|
Torsion of optical cable
|
|
|
≥15N
|
||
|
Drop performance
|
|
|
Allow 10 drops under 1.5m height without abnormal performance
|
||
|
Operation temperature
|
|
2.0x3.0mm (Ttap Fast Connector)
|
-10℃~+70℃
|
||
|
|
|
2.0mm,3.0mm (Ttap Connector)
|
-40℃~+80℃
|
||
|
|
|
5.0mm (Ttap Connector)
|
-40℃~+80℃
|
||
|
Hot and humid working environment
|
|
|
Long term operation under 90% relative humidity ,70 ℃
|
||
