White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material

100 pieces
$0.02/pieces >=100 pieces
White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material
Features Gallery Product Description Request A Quote
Type: Fiber Identifier
Network: Wireless Lan
Color: White
Length: 6cm
Port: Shenzhen
High Light:

Fiber Optic Protection Sleeve 6cm


Ribbon Fiber Optic Protection Sleeve


White fiber protection sleeve

Basic Infomation
Place of Origin: China
Brand Name: OEM
Certification: RoHS, CE
Model Number: Ribbon fiber optic sleeves
Payment & Shipping Terms
Packaging Details: in pp bag then in carton
Payment Terms: T/T, Western Union
Supply Ability: 100000 Piece/Pieces per Day
Product Description

Hot Sales Good Price And Quality Ribbon Fiber Optic Splice Protection Sleeves From China Factory

Ribbon Fiber Fiber Optic Protection Sleeve

Product Description


Ribbon Fiber Fiber Optic Protection Sleeve is 40mm,50mm and 60mm heat shrinkable sleeve for single fiber and 6 cores,12 cores fiber optic protection sleeve for ribbon fiber cable.

Ribbon Fiber Fiber Optic Protection Sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing. The sleeve can be divided into two types (single sleeve and ribbon sleeve) according to the function. The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function.Ribbon sleeve means there are several cores for the fiber. So the mass sleeve includes 4cores, 6cores, 8cores, 12 cores (for types).


fiber series fusion splice protection sleeve is designed to accommodate 2 – 12 ribbon fiber. Stock lengths are 40mm, but are also available in a new 30mm length for smaller packaging requirements. This product is constructed with an inner EVA meltable adhesive tube, a polyolefin heat shrink outer tube and either single or dual strength members. Our single strength member sleeve which has become an industry standard, has an after shrink diameter of 4.9 X 4.4mm, and utilizes a special glass member.


Our dual strength member sleeve is designed to “sandwich” the ribbon, thus eliminating any undue stress on the fiber, and has an after shrink diameter of 5.7 X 4.9mm. This option is available in a variety of glass and special high temperature plastic member combinations. The tubes are clear to allow viewing of the fiber during and after splicing. The entire assembly is designed to ensure that all members maintain perfect alignment during shipping, handling and shrinking.



Product name: Fiber Optic Splice Sleeve
Country of origin: Ningbo,China
Application: FTTH
Diameter of pin: 1.0mm/1.2mm/1.4mm
Pin count: 1
Packing: 100 pcs /bag
Material: EVA



















1.Single holed(preshrunk)ends eliminates improper fiber threading
2.Smooth,deburred stainless steel reinforcing member ends decrease the risk of fiber damage during installation
3.Extended liner length prevents contact between the fiber and ther backbone
4.Clear sleeve design persign permits easy centering of splice before heating
5.Sealing structure makes the splice free from effect of temperature and humidity from environment

6.Protecting splicing point
7.Improve mechanical strength
8.Simple operation, reducing the risk of fiber damage during installation
9.Does not affect the optical characteristics of the optical fiber
10.Sealing structure to have good resistance of temperature and humidity performance




1.Fusion splicing
2.Fiber cable protecting

3.FTTH system

4.Rack-mount & Wall-mount terminal box

5. Fiber Opitc Splice Closure

6. optical fiber switch box and so on continue protection


White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material 0

White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material 1

Our Company

We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. With years of experiences in the fiber optic industry, our factory is fully equipped over 5000 square meters and more than 30 non dust production lines .About 250 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 15 production lines for standard jumper and 8 PLC Splitter production lines. The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on. All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, our fiber optic is looking forward to cooperate with you.

White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material 2


We always learn new technology by investing in production facilities, engineering process control systems, and talent development to maintain our status as a leading fiber optic connection solutions.

Packing & Delivery



Within 1-2 working days


Wholesale orders

3-7 working days according various quantities

White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material 3
White Ribbon Fiber Optic Protection Sleeve 6cm Length EVA Material 4

1. How many staff's we have?
Answer: About 200 well-trained staff and engineers.

2. What's our main products?
Answer: We dedicate to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.

3. What is the area of the factory?
Over 2500 square meters
More than 18 non dust productions lines in total
1 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines

4. What certificate we have?
Answer: ISO 9001: 2015, RoSH, CE, High and New Tech Enterprise Certficate.
