Name: FTTX Fiber Optic Cable Checker OPM-TQ110 For CATV Telecommunications
Brand: ODM/OEM
SKU: OPM-TQ1XX
Price: 45.00 USD
Availability: InStock
Rating: 4.5 (127 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Type: Fiber Optic Cable

Use: FTTX

Warranty Time: 1 YEAR

Detector Type: InGaAs

Interface Type: FC/PC(Optional: SC/ST)

Power Measuring Range(dBm): -50~+26, -70~+10

Measuring Wavelength(nm): 850/1300/1310/1490/1550/1625

Precision: ±0.01dB

Storage: 1000

Power Supply: 3 * 1.5V Dry Batteries

Battery Life: >200h

Operating Temperature: -10℃~+60℃

Storage Temperature: -25℃~+70℃

High Light:

FTTX Fiber Optic Cable Checker

CATV Fiber Optic Cable Checker

Basic Infomation

Place of Origin: China

Brand Name: ODM/OEM

Model Number: OPM-TQ1XX

Payment & Shipping Terms

Packaging Details: 1pc/carton

Payment Terms: T/T, Western Union

Supply Ability: 50 Set/Sets per Month

Gallery

FTTX Fiber Optic Cable Checker OPM-TQ110 For CATV Telecommunications

Product Description

Fiber Optic Cable Checker Tool Kit Fiber Optic Power Meter OPM-TQ110/120 for CATV Telecommunications Engineering Maintent

Product Description:

OPM-TQ1XX series of low-power basic optical power meter use the most advanced dedicated integrated chip for hand-held instrumentation to achieve ultra-low power operation, optical fiber communication, CATV system construction and the process of maintenance.

Feature

◆ Portable design.
◆ FC/PC adapter(SC/ST customized)
◆ High quality measuring
◆ 1000 data storage
◆ Available for SM & MM fibers
◆ Low power consumption, 200 hrs working
◆ Available for FTTH optic power test

Specification

Technical Specifications	OPM-TQ110	OPM-TQ120
Detector Type	InGaAs
Interface Type	FC/PC(Optional: SC/ST)
Power Measuring Range(dBm)	-50~+26, -70~+10
Measuring Wavelength(nm)	850/1300/1310/1490/1550/1625
Precision	±0.01dB
Storage	1000
Power Supply	3 * 1.5V dry batteries
Battery Life	>200h
Operating Temperature	-10℃~+60℃
Storage Temperature	-25℃~+70℃
