Name: 8 Core Fiber Optic Terminal Box For NAP ODP FTB FTTH Uncut Cable Fiber Access
Brand: ODM/OEM
SKU: FTTH-004
Price: 6.50 USD
Availability: InStock
Rating: 5 (104 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Type: Fiber Optic Terminal Box

Use: FTTH, FTTH

Warranty Time: 2

Network: Bluetooth, Wired LAN, ONVIF, Ip, 4g, 3G

Product Name: FTTH 8 Core Fiber Optic Terminal Box

Adaptor Ports: 8

Splitter Suit: 1*8

No. Of Fiber: 8

Material: ABS+PC Mixed Material

Color: White

Cable Diameter: 5mm-10mm

Size: 200mm(W)x215mm(H)x54mm(D)

Certificate: ISO9001, ROHS

High Light:

8 Core Fiber Optic Terminal Box

NAP Fiber Optic Terminal Box

FTTH fiber access terminal box

Basic Infomation

Place of Origin: China

Brand Name: ODM/OEM

Certification: RoHS, CE

Model Number: FTTH-004

Payment & Shipping Terms

Packaging Details: Individual box or according to customer's request

Payment Terms: T/T, Western Union

Supply Ability: 10000 Piece/Pieces per Day

Gallery

8 Core Fiber Optic Terminal Box For NAP ODP FTB FTTH Uncut Cable Fiber Access

Product Description

8 core 1:8 plc pigtails black white NAP ODP FTB FTTH uncut cable fiber acess terminal splitter box

Unload or Preloaded with 1:16 PLC fiber splitter with SC/UPC, SC/APC fiber adapters

* Free Waterproof type Fiber Distribution Box Sample

* Made of Premium Grade Flame Resistant Material

* Suitable to SC/UPC or SC/APC Fiber Adapters & Pigtails

* Reasonable Bending Radius for Fiber Protection

* Can be used with Waterproof Adapter for Fast Connection

* Allow outdoor cable splitting fusion

* IP68 Waterproof grade

Basic Information

16 ports Outdoor Waterproof Wall Mountable FTTH Fiber Splitter or Cable Distribution Box is designed for wall mounted or pole mountable.It has 4 splice trays for managing the fiber pigtails. The material is of PC/ABS alloy.

APPLICATION

1.Widely used in ftth access network. 2.Telecommunication networks 3.Catv networks 4.Data communications networks 5.Local area networks

FEATURES

1.Industry Standard User Interface, be made of high impact plastic. 2.Can accommodate 1x4 & 1X8 PLC splitter. 3.Anti-UV, Ultra violet resistant and rainfall resistant. 4.Up to 8 FTTH drops. 5.Wall and pole mountable. 6.2 inlet ports, 8 outlet ports. 7.Special cable fixed position, ensure the cable fixed pulled off force after not less than 50 N. 8.Job stress: 70 kpa to 108 kpa; 9.Using the temperature:- 40 ~ + 60 ℃ 10.Relative humidity: ≤95% (+ 40 ℃). 11.Protection grade: IP55.

Items	Specification
Product Name	8 core terminal splitter box
Dimensions (WHD,mm)	200mm(W)x215mm(H)x54mm(D)
Number of Cable Entrance(s) and Exit(s)	2/8
Adapter Capacity (Fiber Count)	Adapter Capacity (Fiber Count)
other Accessories	Wall mounting kits,Screws,Cable tie,Heat shrink protective sleeves,Key
Installation (Wall-mounted/Pole-mounting)	Wall-mounted/Pole-mounting

Company Profile

We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. With years of experiences in the fiber optic industry, our factory is fully equipped over 5000 square meters and more than 30 non dust production lines .About 250 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 15 production lines for standard jumper and 8 PLC Splitter production lines. The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on. All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, Our fiber optic is looking forward to cooperate with you.

FAQ

Q1. Do you provide OEM ODM service ? Yes, we can print your logo or label on the products or on the box.

Q2. How can you guarentee the quality ? Build on our perfect quality management system, all of our products were 100% tested before the shipment.

Q3. What is your delivery time ? Generally, sample: 3~5 working days. formal order: 7-10 working days.

Q4. What's the method of shipment? We accept all shipment , such as Delievery,ocean transport, land transport , airport transport.

Q5. What's the Payment? We accept all payments , such as LC,TT,DP,DA,Paypal,Western Union,Money Gram.

Q6. Do you provide sample service? A: Yes, we provide free or low price samples for you to test and check quality. Mixed samples are acceptable.
