Fiber to the home(FTTH)
Fiber to the building(FTTB)
Local area networks
Wide area networks
Small size and light weight for easy installation compact body.
Easy installations: Ready for wall mount – installation kits provided.
Lower layer for splicing .
Upper layer for cross-connecting and fiber distribution.
Fully stable adapter panel, no risk of movement.
Fiber can get in from bottom or side
|
Dimensions and Capability
|
|
|
|
dimensions(W*H*D)
|
270mm*220mm*100mm
|
|
|
Adapter Capacity
|
16xSC;16xLCDX;1x16 PLC Splitter
|
|
|
Number of Cable Entrance/Exit
|
2/16
|
|
|
Optional Accessories
|
Adapters, pigtails
|
|
|
Insert Loss
|
≤0.2dB
|
|
|
UPC Return Loss
|
≥50dB
|
|
|
APC Return Loss
|
≥60dB
|
|
|
Weight
|
1.8KG
|
|
|
|
|
|
|
Shipping Information
|
|
|
|
Pakage Contens
|
Distribution box, 1 unit; Keys for lock, 2keys
|
|
|
|
Wall mount installation accessories,1 set
|
|
|
Package dimensions(W*H*D)
|
270mm*200mm*100mm
|
|
|
Weight
|
1.8KG
|
|
