No. of cable
|
|
2~8
|
10~12
|
14~24
|
|||
Fiber Model
|
|
G.652D
|
|
|
|||
|
Material
|
Steel Wire
|
|
|
|||
|
Diameter(±0.05)mm
|
0.8
|
0.8
|
0.8
|
|||
|
Material
|
PBT
|
|
|
|||
|
Diameter(±0.06)mm
|
2.1
|
2.4
|
2.8
|
|||
|
Thickness(±0.03)mm
|
0.32
|
0.35
|
0.4
|
|||
|
The Max.Core NO./Tube
|
8
|
12
|
24
|
|||
Water Blocking layer(Material)
|
|
Water Blocking Tape
|
|
|
|||
|
Material
|
Steel Strip
|
|
|
|||
|
Thickness(±0.03)mm
|
0.25
|
|
|
|||
|
Material
|
MDPE
|
|
|
|||
|
Thickness(±0.2)mm
|
2
|
|
|
|||
Cable Diameter(±0.2)mm
|
|
7.9
|
8.1
|
8.5
|
|||
Cable Weight(±5)kg/km
|
|
60
|
63
|
68
|
|||
|
Without Tension
|
10.0×Cable -φ
|
|
|
|||
|
Under Maximum Tension
|
20.0×Cable -φ
|
|
|
|||
Temperature range(℃)
|
Installation
|
-20~+60
|
|
|
|||
|
Transport&Storage
|
-40~+70
|
|
|
|||
|
Operation
|
-40~+70
|
|
|
