No. of cable
|
|
|
2~24
|
||
|
Fiber Model
|
|
|
50/125(OM2)
|
||
|
Strength Member
|
Material
|
|
Steel Wire
|
||
|
|
Diameter(±0.05)mm
|
|
0.8
|
||
|
Loose Tube
|
Material
|
|
PBT
|
||
|
|
Diameter(±0.06)mm
|
|
3.0
|
||
|
|
Thickness(±0.03)mm
|
|
0.4
|
||
|
|
The Max.Core NO./Tube
|
|
24
|
||
|
Water Blocking layer(Material)
|
|
|
Water Blocking Tape
|
||
|
Armoring
|
Material
|
|
Steel Strip
|
||
|
|
Thickness(±0.03)mm
|
|
0.25
|
||
|
Outer Sheath
|
Material
|
|
MDPE
|
||
|
|
Thickness(±0.2)mm
|
|
2.0
|
||
|
Cable Diameter(±0.2)mm
|
|
|
9.0
|
||
|
Cable Weight(±5)kg/km
|
|
|
70
|
||
|
Min. bending radius
|
|
Without Tension
|
10.0×Cable-φ
|
||
|
|
|
Under Maximum Tension
|
20.0×Cable-φ
|
||
|
Temperature range
(℃) |
|
Installation
|
-20~+60
|
||
|
|
|
Transport&Storage
|
-40~+70
|
||
|
|
|
Operation
|
-40~+70
|
||
