* Central tube filling compound ensure good moisture resistance performance
|
No. of cable
|
|
|
6
|
12
|
24
|
||||
|
Fiber Model
|
|
|
G.652D
|
|
|
||||
|
Strength Member
|
Material
|
|
FRP
|
|
|
||||
|
|
Diameter(±0.05)mm
|
|
2.1
|
|
|
||||
|
Loose Tube
|
Material
|
|
PBT
|
|
|
||||
|
|
Diameter(±0.06)mm
|
|
2.0
|
2.0
|
2.4
|
||||
|
|
Thickness(±0.03)mm
|
|
0.35
|
0.35
|
0.35
|
||||
|
|
The Max.Core NO./Tube
|
|
6
|
12
|
24
|
||||
|
Outer Sheath
|
Material
|
|
MDPE
|
|
|
||||
|
Cable Diameter(±0.2)mm
|
|
|
7.5
|
|
|
||||
|
Cable Weight(±5)kg/km
|
|
|
55
|
|
|
||||
|
Span(m)
|
|
|
100
|
|
|
||||
|
Min. bending radius
|
|
Without Tension
|
10.0×Cable-φ
|
|
|
||||
|
|
|
Under Maximum Tension
|
20.0×Cable-φ
|
|
|
||||
|
Temperature range
(℃) |
|
Installation
|
-20~+60
|
|
|
||||
|
|
|
Transport&Storage
|
-40~+70
|
|
|
||||
|
|
|
Operation
|
-40~+70
|
|
|
||||
